Home /Products/Passive Piezo Buzzer/PPO 17*7mm Ac Black Sound Electromagnetic Passive Magnetic Piezo Buzzer 12V 4KHZ

PPO 17*7mm Ac Black Sound Electromagnetic Passive Magnetic Piezo Buzzer 12V 4KHZ

1 Piece
MOQ
$0.12(1 - 999 Pieces) $0.08(1000 - 4999 Pieces) $0.07(5000 - 49999 Pieces) $0.06(>=50000 Pieces)
Price
PPO 17*7mm Ac Black Sound Electromagnetic Passive Magnetic Piezo Buzzer 12V 4KHZ
Features Gallery Product Description Request A Quote
Features
Specifications
Model Number: YNR-17070
Type: Buzzer, Buzzer
D/C: 20210506
Material: PPO, PPO
Color: Black, Black
Input Type: AC, AC
Voltage - Rated: 12V
Voltage Range: 1-20V
Frequency: 4000HZ, 4000HZ
Technology: Piezo, Piezo
Operating Mode: Single Tone
Current - Supply: 3MA
Operating Temperature: -20°C ~ 60°C, -20°C ~ 70°C
Mounting Type: Through Hole
Size / Dimension: 17*7mm
Height - Seated (Max): 7MM
Voltage - Input (Max): 20V
Height (Max): 7mm
Rated Voltage: 5V
Product Name: Sound Electromagnetic Passive Magnetic 12V Piezo Buzzer 4KHZ
Install: Through Hole
Rated Voltage:: 12V
Basic Infomation
Model Number: YNR-17070
Payment & Shipping Terms
Packaging Details: Pakcaging in one Box
Supply Ability: 100000 Piece/Pieces per Week
Product Description
View More>>
17*7mm 12V AC Black Sound Electromagnetic Piezo Buzzer
Products Description
Product Name
DC Black Electromagnetic Piezo Buzzer
Type
Piezo Buzzer
Rated Voltage
12V
Operating Voltage
1V-20V
Operating Temperature
-20°C ~ 70°C
Storage Temperature
-30°C ~ 80°C
Rated Current(Max.)
≤5
Sound Output at 10cm（dB）
≥85
Resonant Frequency
4000HZ
Input Type
AC
Technolgy
Piezo
1. Piezo Buzzer Dimensions
2. Piezo Buzzer Test Circuit
3. Piezo Buzzer Frequency Response
4. Piezo Buzzer Test Condition
